sinus-Obliquus

FOR THE TREATMENT OF MAY-THURNER SYNDROME (MTS)
  • Unique stent design
  • Hybrid and oblique
  • High flexibility of the open-cell segments
  • Improves verifiably the quality of life

MORE QUALITY OF LIFE³, SPECIALLY DESIGNED FOR THE TREATMENT OF MTS.

The sinus obliquus is the only self-expanding hybrid stent with a beveled proximal stent tip in a closed-cell design used to treat symptomatic obstruction of the iliac vein near the bifurcation to the inferior vena cava. Approximately 50-60%¹’² of patients with iliofemoral venous thrombosis have compression of the predominantly left iliac vein by the right iliac artery – the so-called May-Thurner syndrome. The special design of the sinus obliquus enables the treatment of this special indication.

Uniqueness

  • The ONLY stent with oblique design, specifically for MTS.
  • Radial force and flexibility are applied where they are needed.

Oblique Power Crown

  • Lower risk of thromboembolism or occlusions due to the adapted radial force of the closed-cell portion of the stent.

Repositionability

  • Enables precise stent placement increasing the chances of a successful intervention.

Study Data – TOPOS 12-month-results³

  • Performance of the sinus-Obliquus Stent: 100%.
  • Primary Patency: 83%
  • Improvement in all 4 relevant clinical scores:
    Villalta score (3/10) / rVCSS (3/8) / VAS (Pain 1/4) /Civic-20 (Quality of Life 27/45)

The pain of the patients has been shown to be reduced and their quality of life was significantly improved.

1 Prof. Dr. Schlager, Endovaskuläre venöse Rekanalisation: Stents für die Venen | Ärztezeitung (aerztezeitung.at), 25.09.2018

2 Schleimer et al, The treatment of Post-Thrombotic Syndrome, Dtsch Arztebl Int., 2016

3 Sebastian et al, Twelve-month clinical outcomes of a hybrid oblique self-expanding nitinol stent used for the treatment of post-thrombotic syndrome with common iliac vein compression: The TOPOS study, sagepub.com., 2021

Order code
Length of application device (cm)
Application device (Ø/F)
Guide wire (Ø/inch)
Stent (Ø/mm)
Stent length (mm)
8414-01-8080
100
10
.035
14
80
8414-01-8100
100
10
.035
14
100
8414-01-8150
100
10
.035
14
150
8416-01-8080
100
10
.035
16
80
8416-01-8100
100
10
.035
16
100
8416-01-8150
100
10
.035
16
150
8418-01-8100
100
10
.035
18
100
